HEPA filter H14 50m3/h (open)
HEPA filter H14 50m3/h (open)
HEPA filters are mounted on glove boxes for a variety of applications: known for trapping hazardous particles and protecting operators, they are also used to reduce the level of particles in a controlled environment.
- Trapping of fine particles, dust, fumes, bacteria, aerosols.
- Used in the pharmaceutical sector and all sectors with hazardous processes, they guarantee the containment of contaminating or toxic micro-particles and protect the operator and the environment.
- Used in advanced research and nanoscience, they prevent the spread and contamination of samples by unwanted particles.
Applications:
Technical Specifications
Technical specifications of a HEPA H13 filter for glove box:
|
50m3/h “open” type filter (also available in “closed” type)
|
|
Mounted on the main ventilation circuit of a glove box under air or inert gas, possibly mounted in a filter box.
|
|
Protective mounting of pressure gauges or other sensors in a protected or dust-controlled enclosure.
|
|
Efficiency mpps 99.993% for particles at 0.15µm in accordance with standard EN1822-1.
|
Compatibility
This equipment can be installed on the following glove box models
Controlled atmosphere glove box for the protection of products < 1PPM H2O – O2
Glove box designed for controlled atmosphere processes < 1PPM H2O – O2
Glove box designed for research and industry for all applications < 1PPM H2O – O2
Modular glove box for gas flushing. Easy to use, low maintenance.
Adjustable glove box under filtered air for protection of the operator and / or the environment.
